Impermeable Material Mini Inkjet Printer For Date Batch Serial Number
FEATURE
- Quick-dry balck ink used industrial non-contact small character inkjet printers
- Print consistently high quality images even on structured and uneven surfaces
- Print features include date, time, batch number, logo and trademar
- Easy to be integrated at any position of the production line
- User friendly interface and most reliable ink system
- Large memory, and the 8.4'' TFT bright clear touch screen
- Multitask system, printing and editting at the same time
| Printable Lines | Digital or English within 5 lines |
| Max.Printable Dot Matrix | 32*32 dot matrix |
| Memory Capacity | up to 1000 messiges |
| Max.Print Speed | 800 characters per second(5*7 dots) |
| Printable Font Height | 1.5mm-20mm adjustable |
| Operation Interface | Can Switch English and Chinese menu |
| Printable Content | date,time,lot number,seriel number etc. |
| Print Distance | 30mm Max from printhead bottom to substance surface |
| Printhead Throat Length | 3m(customizable) |
| Ink color | Black,Blue,red etc. |
| Power source | AC220V/380V 50Hz 100AV |
APPLICATIONS
Automobile part, Beverages, Cosmetics, Electronic Component, Foods, Pharmaceuticals,
Building material, Eggs, Pipes & Tubes, Cables & Wires etc.
HYDRAULIC SYSTEM
- Compact design
- Full automatic viscosity control and pressure control
- Diaphragm pumps with reliability, longer life, low maintenance cost than gear pump
- Electronic control system completely separated design from hydraulic system
PRINT HEAD
- Compatible design, maintenance friendly
- Automatic ink stream on when start up and ink stream suck back when turn off
- Nozzle size: 58 μ M standard, 52 to 65 μ M optional
- Easily accessible and can be installed in any position
- Distance from print head to print surface 1mm~30mm
TECHINICAL SPECIFIFATION
1. Print Line: 1-5 lines (5 X 5 dots)
2. Print Dots: Figure & letter 5 X 5, 5 X 7, 8 X 10, 8 X 12, 12 X 16, 16 X 16, 24 X 24, and user-defined within 32 X 32
3. Memory: 1000 message, 1000 graphics
4. Print Speed: 800 character per second ( 5 X 7 dots)
5. Letter Height: 1-20mm
6. Operating interface: Chinese, English
7. Print objects: Chinese, English, figues, date, time, and numbering of reset
8. Material: Metal, plastic, glass, woode, tubing, electrical wire, cable etc
9. Font Width: Up to 9 times
10. Nozzle Connection Tube: 3M
11. Communication Interface: USB and RS232
12. Ink Color: Black, blue, red etc
13. Consumption of Ink: 70 millions character per litre
14. Operating Environment: 5-45 degree centigrade, below 90%(humidity)
15. Power Source: AC220V / 380V 50Hz 100AV
MARKING SAMPLES
Product Tags:
|
|
Impermeable Material Mini Industrial Inkjet Printer For Date Batch Serial Number Images
|
